Band pass filter for NOAA 137MHz satellites

Field of use :

• Professional band pass filter with high Q components
• You can use it in transmission up to 35Watt of power
• Strong attenuation of unwanted frequencies

Uniqueness :

• All the band pass filters of our production are calibrated one by one for the minimum loss on the frequency for which it was designed.
• Innovative filter with high Q components

Connectors :

• N Female or male 50 Ohm or SO239 : Amphenol or similar high quality
• N female or male 50 Ohm or SO239 : Amphenol or similar high quality

Materials :

• Cylindrical structure made of anticorodal aluminum alloy 6000.
• Red anodic anodizing

Technical features :

• Attenuation at 88, 98 and 108 MHz => at 60dB
• High quality Amphenol N or similar connectors
• 35 Watts input max
• Reversible filter
• Insertion loss at 137.5MHz : approx. 1.5dB
• Impedance : 50Ohm
